Conduit Comparison

Type	NC	CPTA	HTC	CPC	NCV	HNC	GPA
Conduit Material	Polyamide 6	Polyamide 6	Modified Co-Polyester	Co-Polyester	FR Polyamide 6	Polyamide 12	Polyamide 6 / Polypropylene blend
Conduit Weight	Standard	Light	Medium	Medium	Standard	Standard	Medium
Slit Version Available	✓	✓	✓
Colours Available	◼Ral 9005 ◼Ral 2003	◼Ral 9005 ◼Ral 2003	◼Ral 9005	◼Ral 9005 ◼Ral 2017	◼Ral 9005	◼Ral 9005	◼Ral 9005
Temperature range
Long term static min.	-40°C	-40°C	-50°C	-50°C	-40°C	-60°C	-5°C
Long term static max.	+120°C	+120°C	+150°C	+135°C	+120°C	+105°C	+90°C
Short term (3000hrs)	+150°C	+135°C	+175°C	+150°C	+150°C	+120°C	+105°C
Short term (200hrs)	+175°C	+150°C	+190°C	+175°C	+170°C	+135°C	+105°C
Characteristics
UV Resistance	◼◼◼◼	◼◼◼◼	◼◼◼◼	◼◼◼◼	◼◼◼◼	◼◼◼◼	◼◼◼◻
Flexibility	◼◼◼◻	◼◼◼◼	◼◼◼◼	◼◼◼◼	◼◼◼◻	◼◼◼◼	◼◼◼◻
Fatigue Life	◼◼◼◼	◼◼◼◻	◼◼◼◼	◼◼◼◼	◼◼◼◻	◼◼◼◼	◼◼◻◻
Ext. wear resistance	◼◼◼◼	◼◼◼◼	◼◼◼◻	◼◼◼◻	◼◼◼◼	◼◼◼◻	◼◼◻◻
Fire performance: All products are Self Extinguishing and Halogen Free
Low smoke toxicity	✓	✓	✓	✓	✓	✓
UL94 V0					✓
UL94 V2				✓
UL94 HB	✓	✓	✓			✓	✓
R118	✓
Approvals: All products are CE Approved, RoHS Compliant, (ELV) EU200/53/EC
ADR Approved	✓
Chemical Resistance: All products are suitable for; IRM 903 (ASTM Oil No.2), Diesel Oil, Ethylene Glycol, Lubricating Oil, Parafin Oil, Petrol, Sodium Chloride, Sodium Hydroxide (10%), Transformer Oil, Vegetable Oil, Sea (Water)
Methyl Alcohol	/	/	✓	✓	/	✓	✓
Urea	✓	✓	✓	Not Tested	✓	✓	✓
